Hardy Clip 100 Standing Seam Panel
Technical Details
- Residential and Commercial Application.
- 1″ rib height, Integral Snap-Lock Standing Seam.
- 13″ or 17″ nominal width (17″ nominal width standard)
- Can be made in lengths from 3 feet to 30 feet.
- Used on roofs with pitches of 3/12 or above
- 26 gauge AZ50 Galvalume steel Standard
- UL 790 Fire Resistance Class A
- UL 2218A Impact Resistance Class 4
- Available in over 60 colors. (See color chart/matrix below)
- .032 Aluminum, or 24ga premium steel w/Kynar® paint and 26 gauge premium steel w/Textured Paint or Low Gloss paint available. (500 lin. ft min. order)
- Limited Lifetime Paint and Steel Warranty
- Ten in-stock 26 gauge colors (See color chart above)
- Five in-stock 24 ga. PVDF colors (Regal White, Matte Black, Aged Bronze, Charcoal Gray & Cityscape)
- Current Lead Time In-stock colors: 3-10 days
- Lead time for special order colors/gauges: 1-6 weeks
Architectural System for Commercial & Residential
Our Hardy Clip 100 standing Seam Panel is a hidden fastener standing seam panel attached with clips and is one of the best-standing seam panels that metal roofing companies have to offer. Although similar to our Legacy Hardy Clip and Hardy Clip 150 panels, the Hardy Clip 100 panel has a shorter rib height for a more sleek design. The Hardy Clip 100 can also be made in steel up to 24 gauge. This provides a stronger panel and a more modern look. Unlike the nail fin style standing seam panels commonly available to the residential market, which has a nail fin for attaching the panel to the deck, our 1″ integral snap-lock standing seam panel is attached with clips. This approach helps to reduce oil canning because it allows the panel room to expand and contract. For an even greater reduction in oil canning and a stronger panel, you can upgrade to use 24 gauge steel. Additionally, this panel is suitable for installation on slopes greater than a 3/12 pitch.
![](https://images.midmichiganmetalsales.com/images/2022/08/TEXTURED.jpg)
- Visually attractive with rich and deep appearance
- Reduces the appearance of oil-canning with a unique textured finish
- Improved durability with a more scratch-resistant finish
- Comes with a Limited Lifetime Paint and Steel Warranty
- Available in thirteen (13) different colors
Textured Paint for 26 Gauge Steel
TEXTURED is a one-of-a-kind textured finish that offers an unparalleled level of visual depth, dimension, and durability. This innovative coating not only enhances performance but also elevates the aesthetics of traditional painted surfaces. By diffusing and redirecting light, TEXTURED provides a captivating appearance while minimizing the visibility of oil-canning.
TEXTURED has been meticulously developed to provide not only a more durable surface, but also enhanced resistance to scratching and scuffing commonly found with low gloss or matte finishes. It maintains the same excellent film integrity, exceptional weathering performance, and remarkable resistance to chalking and fading that ULTRA-CLAD is highly regarded for.
Additional Product Information
MMMS 26 gauge Steel Standard Color Chart (JPG)
Sheffield Metals Special Order 24ga Steel & .032 Aluminum Kynar Colors(PDF)
Sheffield Metals Low Gloss 26ga Steel Colors (PDF)
Ultra Clad Color Chart Special Order 26ga & 24ga Steel colors (PDF)
East Lake Metals Special Order 24ga Steel, and 0.032 Aluminum Colors(PNG)
Available standard trims (PDF)
Installation Guide (PDF)
